Frezë CNC me shpejtësi të lartë

CHMER HE86GT

For sale: a professional, high-speed machining center of the HSC (High Speed Cutting) class.
The machine's main advantage is its exceptionally efficient spindle, reaching up to 30,000 rpm, mounted on a precise HSK-50E taper. Combined with a rigid and heavy construction (weight approximately 7,500 kg), the machine guarantees perfect surface quality, rapid milling speeds, and the ability to operate stably with micro-tools.
An ideal choice for the precise machining of molds, dies, aluminum parts, light metals, and plastics.

Technical specifications:
Dwedpfx Abozuzp Hs Usc

Spindle and drive (main HSC advantage):
• Spindle speed: 3,000 to 30,000 rpm (High Speed Cutting)
• Spindle taper: HSK-50E (ensures excellent balance and safety at high speeds)
• Spindle motor power: 15 kW

Dimensions and working area:
• Table dimensions: 850 x 600 mm
• Maximum, uniform table load: 800 kg
• Dimensions of T-slots: 16 mm x 5 pcs.
• Footprint (overall dimensions): 3390 x 2870 x 2750 mm

Travel ranges (axes):
• X-axis travel: 800 mm
• Y-axis travel: 600 mm
• Z-axis travel: 400 mm
• Distance from spindle to table surface: 160 – 560 mm

Dynamics and accuracy:
• Positioning accuracy: ±0.005 mm
• Positioning repeatability: ±0.0015 mm
• Maximum working feed rate: 20 m/min
• Maximum rapid feed rate: 30 m/min

Tool magazine and media:
• Tool magazine capacity: 16 tools
• Maximum tool diameter: Ø20 mm
• Dielectric fluid tank capacity: approx. 200 liters

Power supply and installation:
• Power requirement: 45 kW
• Preferred fuse rating: 63 Amp (time-delay “C”)
