Makinë bluarëse cilindrike

Studer S33

CNC CYLINDRICAL GRINDER STUDER S-33 CNC
Year: 2007 - Fanuc 21i-TB
1 External Grinding Spindle
Country of Origin: Switzerland
Voltage: 380/50/3
Net machine weight: 4,000 kg

TECHNICAL SPECIFICATIONS

Distance between centers: 600 mm
Center height: 175 mm
Maximum workpiece weight: 80 kg

Longitudinal Slide Z
Max. travel: 800 – 1,150 mm
Travel speed: 0.001 to 10,000 mm/min
(early 2000’s model: 0.001-5,000 mm/min)
Resolution: 0.0001 mm

Cross Slide X
Max. travel: 285 mm
Travel speed: 0.001 to 20,000 mm/min
(early 2000’s model: 0.001-10,000 mm/min)
Resolution: 0.0001 mm

Wheelhead (universal version)
Swiveling range: -15° to 225°
(early 2000’s model: -15° to 195°)
Swivel axis: 2.5 / 1 ° Hirth
Drive power: 7.5 or 9 kW or 11 kW
Grinding wheel: 500x63 (80/110F5) x203 mm

Workhead
Rotational speed: 1 – 1,500 min-1
Mount taper: MT4 or MT5 / ISO 50
Drive power: 1.6 or 3.0 or 4.0 kW

Tailstock
Mount taper: MT3 or MT4
Crsdpew T Sh Ejfx Ad Dei
Quill stroke: 35 / 50 mm
(early 2000’s model: 35 mm)
Quill diameter: Ø 50 mm
Fine adjustment: +/- 40 µm

Control system: Fanuc 21i-TB

All technical details are provided in good faith but subject to errors or omissions.
