HIGH-PERFORMANCE DECANTER CENTRIFUGE – CBB DECANTER SERIES I CD 45IC

CBB Decanter Centrifuge Series I CD 45IC, flow capacity up to 37 m³/h, drum diameter Ø430 mm, separation efficiency 95–98%, drum motor 30 kW IE3, scroll fitted with tungsten carbide wear protection and HV 3000 bushings. Complete with DPC control panel featuring Touch Screen and accessory kit.

Main Specifications:
• Brand / Model: CBB Decanter Series I – CD 45IC
• Year of manufacture: 2020
• Type: High-performance decanter centrifuge with hydraulically variable speed
• Hydraulic throughput: up to 37 m³/h (variable depending on product)
• Drum diameter: Ø430 mm – Length 1800 mm
• Maximum centrifugal force: 3820 G
• Separation efficiency: 95–98%
• Liquid discharge levels: 10 adjustable positions
• Machine weight: 3,330 kg
Gkedpfx Adexlki Dspec
• Dimensions: 3796 x 1206 x 1550 mm (L x W x H)

Construction Features:
• Drum and scroll in Duplex stainless steel with tungsten carbide wear protections
• Wear-prone parts in HV 3000 ceramic
• Accessible and fully openable Duplex liquid and solids discharge ports for easy inspection
• Conveying scroll with wear protection and counter-current separation principle
• “Split case” frame and housing for quick maintenance access

Drive System:
• Drum electric motor 30 kW – 4 pole – IE3 – IP55
• Scroll electric motor 0.37 kW – 4 pole – IE2
• Drum drive with inverter (integrated in control cabinet)
• Scroll drive via hydraulic circuit with Cyclo planetary gearbox
• Combined electro-hydraulic system with energy recovery
• DPC (Decanter Process Controller): complete process management, differential speed variation, overload protection, and remote monitoring

QE CD 45I Electrical Cabinet:
• Dimensions: 800 x 600 x 2300 mm – Weight: 330 kg
• Protection: IP55
• Touch screen for parameter management, status display, and alarms
• Integrated DPC (Customer Card CBB Decanter)
• ModBus communication, prepared for remote support
• Complete management for sludge pumps, polymer pumps, sensors, solenoid valves, and automatic wash cycles

Included Equipment:
• Electrical cabinet with DPC + Touch Screen
• Lubrication kit for bearings and gearbox
• Solenoid valve kit for internal/external drum washing
• Spare sensor kit (speed and vibration)
• Spare hydraulic oil filter kit
• Machine manuals + electrical cabinet manual (2 hard copies + 1 digital copy)
