Arburg Allrounder 920S 5000-3200+ robot + conveyor belt

This 3-axis Arburg Allrounder 920S 5000-3200 hydraulic injection moulding machine was manufactured in 2007. It features a maximum clamping force of 5,000 kN, a screw diameter range of 70 to 90 mm, and a maximum shot weight up to 1,860 g. Consider the opportunity to buy this Arburg Allrounder 920S hydraulic injection moulding machine. Contact us for more information about this machine.

• Maximum mold opening force: 150 kN
• Enhanced opening force: 100 / 1,000 kN
• Opening stroke: up to 900 mm
Nsdpsydnigofx Ad Rswb
• Mold height: min. 400 – max. 1,050 mm
• Distance between platens: 1,300 – 1,950 mm
• Tie-bar spacing (H × V): 920 × 920 mm
• Platen size (W × H): 1,280 × 1,280 mm
• Movable platen weight (half): max. 8,000 kg
• Ejector force: max. 800 kN
• Ejector stroke: max. 250 mm
Hydraulics / Drive

• Hydraulic pump motor power: 75 kW
• Dry cycle time (opening stroke 5): 4.5–6.44 s
• Installed total power: 96 kW
• Color: Structural light gray / mint green / red-yellow
• Control cabinet safety standard: DIN EN 60204
• Socket combination: 1 × Schuko, 1 × CEE
Injection Unit

• Screw diameters: 70 / 80 / 90 mm
• Effective screw length (L/D): 23 / 20 / 18
• Maximum shot volume: 1,232 / 1,608 / 2,036 cm³
• Maximum shot weight (PS): 1,125 / 1,469 / 1,860 g
• Plasticizing capacity (PS): 185 / 215 / 250 kg/h
• Maximum injection pressure: 2,500 / 2,000 / 1,580 bar
• Injection rate:
• Without accumulator: 290 / 380 / 482 cm³/s
• With accumulator: 1,188 / 1,552 / 1,964 cm³/s
• Holding pressure: max. 350 / 200 bar
• Screw speed: 47 / 54 / 61 rpm
• Screw torque: 3,500 Nm
• Nozzle contact force: max. 110 kN
• Nozzle stroke: max. 675 mm
• Installed barrel heating power: 6 × 5,500 + 4,300 W
• Installed nozzle heating power: 1,100 W
• Oil fill volume: 590 liters
• Motor + heating fuse rating: 200 A
• Motor fuse: 125125 A
• Heating fuse: 63 A
